RD300D


Model

Input Power Capacity

KVA

Tube Voltage

KVP

X Ray Tube

X Ray Generator

Controller

Size

weight

Max penetration (mm)

Focal Size (mm)

Angle

RD-1805

4

80-180KV

0.9*0.9

40+5°

Dia116*510mm

8.9

32

4.8KG

RD-2305

5

100-230KV

0.9*0.9

40+5°

Dia280*600mm

12

32

5KG

RD-2805

5

150-280KV

2.0*2.0

40+5°

Dia280*600mm

26

45

9kg

RD-300LG

6

150-300KV

2.6*2.6

40+5°

Dia270*810

45

80

1.5KG

RD-3005

6

170-300KV


40+5°

Dia260*600

28kg

52

5kg

RD-3505

7

170-350KV


40+5°

Dia320*650

34kg

55

9kg

RD-3605

7

170-360KV

2.5

40+5°

Dia320*650

34kg

60

9kg

RD-G300

6

30-300KV

2.5*2.5

40+5°

Dia305*880

30

55

11

Technical Specification

Item

Technical Data

AC Power

AC 220V+/-10%, 50Hz

Output

Tube current

5mA

High voltage transfer input voltage fluctuation

+/- 1%



X Ray Generator

Cooling method

Force air cooling

Insulated method

SF6 gas insulation

Soft working pressure (20℃）

0.35~0.45Mpa

Working Condition

Temperature

-30-40℃

Relative Humidity

＜85%

Altitude

1000m

Max Penetration Condition

Steel

A3(mm)

Focal length

600m

Exposure

≤30mAmin

Film

Double-sided lead foil sensitization

Darkroom treatment

20+/-2℃， 5min

Optic density

D≥2.0

The controller

Size


Weight


Timing error

5min +/- 10%

Working Rate

Working & rest 2:1 working rate, the max exposure time 9.5min


Since portable radiographs have been used in industrial flaw detection, almost ALL THE world's STANDARDS HAVE had a 1:1 WORKING mode, in which the time worked equals the time needed to rest. The reason is that the ray tube is hot and needs rest buffer.

Weway HAS DEVELOPED AN UNINTERRUPTED WORKING MODE THAT REQUIRES A MAXIMUM SUPPORT THAT IS REDUCED heat or ACCELERATED heat dissipation. This is the biggest feature of the model. To solve the heat dissipation is not only to increase the radiator this simple method, the key is to reduce the useless power consumption of the ray tube. The control circuit and high voltage generator of this product play a decisive role.

The application of patent technology, the controller and high voltage generator together. The biggest benefit is energy saving and consumption reduction. The efficiency of high voltage pulse transformers is improved, and the effect of feedback is to reduce power consumption.
